Checkline DTW Electronic Torque Wrench

---

1/4" 3/8" or 1/2" Drive

---

Capacity: up to 250.0 lbf-ft

---

5 Models:

• DTW-265i - 265 in-lb / 30 N-m - 1/4" Drive
• DTW-1200i - 1200 in-lb / 145 N-m - 3/8" Drive
• DTW-100f - 100 ft-lb / 145 N-m - 1/2" Drive
• DTW-250f - 250 ft-lb / 340 N-m - 1/2" Drive
• DTW-625f - 625 ft-lb / 850 N-m - 3/4" Drive

The new DTW Electronic Torque Wrenches are designed for simple and precise measurement of industrial, automotive, aerospace and many other applications. The DTW displays Real-Time and Peak torque on a large LCD display in ft-lb, in-lb or N-m, user selectable.

The DTW features High-Lo set points that indicate a desired torque value with a bright LED and audible beep.

Kit Contents

DTW Electronic Torque Wrench CE Certified Carrying Case

Features

• Displays in-lb, N-m, Kg-cm and ft-lb units (User selectable)
• CW and CCW operation
• Peak or Real-Time (track) mode (User Selectable)
• Programmable Target Set-point with audible and visual indicators
• Includes Calibration Certificate
• CE Certified

Specifications

Accuracy	CW - ±2.5% CCW - ±3.5%
Memory	50 Readings
Operation Mode	Peak hold/ Track
Unit Selection	ft-lb, in-lb, N-m
Length	DTW-265i - 390 mm DTW-1200i - 415 mm DTW-100f - 445 mm DTW-250f - 650 mm
Head Type	Lever type Ratchet
Gear Teeth	36
Battery	2x AA
Battery Life	110 Continuous Hours 1 Year Standby
Operating Temperature	-10°C ~ 60°C
Storage Temperature	-20°C ~ 70°C
Humidity	Up to 90% non-condensing

Force Ranges

Model	Capacity	Resolution
DTW-265i	26.5 - 265 Lbf-in	1/4"
DTW-1200i	120 - 1200 Lbf-in	3/8"
DTW-100f	10 - 100 Lb-ft	1/2"
DTW-250f	25 - 250 Lbf-ft	1/2"
DTW-625f	31.3 - 626 lbf-ft Lb-ft	3/4"
