Force Gauge Attachments



  • Shimpo FG-M6CBH60U Carton Box Pull Hook Grip

    Shimpo FG-M6CBH60U Carton Box Pull Hook Grip
    Price: $185.00

    Shimpo FG-M6CBH60U Carton Box Pull Hook Grip
    56 lb (25 kg) capacity
  • Shimpo FG-M6FLMQR20U Film Grip 0.8" Quick Release

    Shimpo FG-M6FLMQR20U Film Grip 0.8" Quick Release
    Price: $675.00

    Shimpo FG-M6FLMQR20U Quick Release Film Grip, 45 lb (20 kg) Max. Capacity
    0.8" (20 mm) width, 0.08" (2 mm) Max. Opening
  • Shimpo FG-M6FPG Grips Fine & Medium Gauge Wire, Ribbon, Tapes

    Shimpo FG-M6FPG Grips Fine & Medium Gauge Wire, Ribbon, Tapes
    Price: $150.00

    Perfect for testing fine and medium gauge wire, ribbon, tape and paper. Two jaw widths and load capacities are available; both can handle material thickness up to .04" (1 mm)

    Shimpo FG-M6FPG Grips Fine & Medium Gauge Wire, Ribbon, Tapes
    Manufacturer: Shimpo
    Warranty: One Year
  • Shimpo FG-M6FTG20U Fat Chuck Tensile Grip

    Shimpo FG-M6FTG20U Fat Chuck Tensile Grip
    Price: $250.00

    Each serrated gripping face is .79" (20 mm) square and can accept samples up to .79" (20 mm) thick.

    Shimpo FG-M6FTG20U Fat Chuck Tensile Grip
    Warranty: One Year
  • Shimpo FG-M6JAC5U Jacob’s Chuck Grip

    Shimpo FG-M6JAC5U Jacob’s Chuck Grip
    Price: $160.00

    Shimpo FG-M6JAC5U Jacob’s Chuck Grip
    Designed for testing low gauge wire and rigid rods; accepts material diameters from .02" (.05 mm) to .20" (5 mm).
    Warranty: One Year
  • Shimpo FG-M6PIN Grips Fine Wires and Filaments

    Shimpo FG-M6PIN Grips Fine Wires and Filaments
    Price: $120.00 - $130.00

    Ideal for gripping fine wires and filaments; three ranges for checking samples of .02", .04", .08" (0.5, 1 and 2 mm) thick.
    Shimpo FG-M6PIN Grips Fine Wires and Filaments
    Manufacturer: Shimpo
    Warranty: One Year
  • Shimpo FG-M6SP010U Spool Grip 100 lb Capacity

    Shimpo FG-M6SP010U Spool Grip 100 lb Capacity
    Price: $220.00

    Shimpo FG-M6SP010U Spool Grip 100 lb Capacity
    Ideal for hard-to-hold items like thread, filaments, etc. The sample is wrapped around the spool, anchored by friction.

    Shimpo FG-M6SP010U: 100 lb / 50 Kg / 500 N

    The Shimpo FG-M6SP010U Spool Grip is ideal for hard-to-hold items like thread, filaments, etc. The sample is wrapped around the spool, anchored by friction.


  • Shimpo FG-M6WTER100 Wire Terminal Test Fixture

    Shimpo FG-M6WTER100 Wire Terminal Test Fixture
    Price: $485.00

    Shimpo FG-M6WTER100 Wire Terminal Test Fixture

    Capacity: 100 lb / 50 Kg / 500 N

    Designed specifically to test the strength of wire/terminal connections. The upper grip consists of a self-aligning wheel with nine equally spaced slots of various terminal shank sizes; an eccentrically mounted, self-tightening bottom grip secures the wire on the other end.
  • Shimpo FG-M6TAP30U Tape Grip

    Shimpo FG-M6TAP30U Tape Grip
    Price: $250.00

    Shimpo FG-M6TAP30U Tape Grip 100 lb Capacity

    Self tightening lever action makes this fixture perfect for testing rubber, tape and paper.
    Warranty: One Year
  • Shimpo FG-TWN Cord and Twine Grip

    Shimpo FG-TWN Cord and Twine Grip
    Price: $245.00 - $325.00

    Shimpo FG-TWN Cord and Twine Grip

    A unique figure 8 wrap of specimen assures a center break and non-locking pins permit quick installation and release. Throat and pin clearance is .375" (9.65 mm) wide with the throat width being .5" (1.7 mm)
    Manufacturer: Shimpo
  • Shimpo FG-WDG Wedge Grip

    Shimpo FG-WDG Wedge Grip
    Price: $400.00 - $975.00

    Shimpo FG-WDG Wedge Grip

    Two capacities for lighter and heavier loads; spring-loaded jaws automatically close on the specimen and tighten as tension is applied. Ideal for testing wires, strip material and plastic tape or films.
  • Shimpo FG-M6PUNCTUREST Puncture Attachment

    Shimpo FG-M6PUNCTUREST Puncture Attachment
    Price: $85.00

    Shimpo FG-M6PUNCTUREST Puncture Attachment
    Warranty: One Year
