Shimpo FTS-HD High Capacity Force Test System

---

1000 lb / 500 Kg / 5000 N Capacity

---

Includes Gauge and Test Stand (FGV-1000HXY + FGS-1000H)

---

Capacity: 1000lbs

The Shimpo FTS-HD High Capacity Force Test System is a high capacity force test system engineered for precise & repeatable measurements of push or pull forces up to 1000lbs. A smooth operating turn-wheel provides a precise 0.1" travel per revolution. The Shimpo FTS-HD heavy duty construction provides repeatable and reliable testing for many years. The Shimpo FTS-HD Force Test System features adjustable height ranges, customizable lengths (for different sample sizes) and an option for a digital length/height meter.

The FTS-HD Force Test System includes the FGV-1000HX Digital Force Gauge and FGS-1000H Mechanical Hand-Wheel Test Stand. The system is designed for precise, accurate measurements.

Features

• 1000 lb / 500 kg / 5000 N Capacity
• Accuracy ± 0.2%
• 200% overload protection
• Measures both compression and tension forces
• 200% overload protection
• Heavy-duty load sensor
• User-selected units of Pounds, Kilograms or Newtons
• Measures both compression and tension forces
• Removable hanger
• 1 Year Warranty
• Includes NIST Calibration Certificate

Specifications

Accuracy	±0.2% full scale
Resolution	0.1 lb, 0.1 Kg, 1 N
Display	4-Digit LCD, 12mm high. Reversible by the push of a button. Minus sign for tension
Display Update	0.05, 0.1, 0.2, 0.3, 0.5, 1 sec
Sampling Rate	1000 times per second
Overload Protection	150% of full scale
Power	Rechargeable Ni-Cad battery or AC through adapter/charger
Auto Power Shut-Off	Yes (not active if adapter/charge is in use)
Battery Life	12 hours (when fully charged)
Recharge Time	Approximately 18 hours when fully discharged
Dimensions	8.43" L x 3.23" W x 2.15" H (214 mm x 82 mm x 54.5 mm)
Weight	78 lb (34 Kg)
Approvals	CE approved
Outputs	RS232C & Analog Output ±1 VDC (through a 12 bit D/A converter)
Overload Output	One NPN OC transistor for tension, one NPN OC transistor for compression
Warranty	1 Year
