This product has been replaced by the Mark-10 EasyMESUR

Mark-10 ESM303 High Performance Motorized Test Stand

Force Gauge sold Separately

Distance Measurement, Break Detection, Load Holding and many other features

Made in the USA, 3 Year Warranty

The Mark-10 ESM303 High Performance Motorized Test Stand is designed for tension and compression measurement up to 300 lb / 1500 N. Its rugged design is suitable for laboratory and production environments. With generous travel, clearance, and depth, a wide range of tests can be performed, including destructive testing, cycling, limit testing to load or distance, load-holding, elongation testing, tensile testing, compression testing, and more.

A simple menu allows the user to program test speed, force and distance limits, cycling, preload, and many other functions, all protected by a password. Save up to 50 profiles to accommodate a range of test methods.

If the Mark-10 ESM303’s clearance is insufficient for the application, its modular mechanical design allows for single and double-column extensions.

The Mark-10 ESM303 High Performance Motorized Test Stand offers and range of optional functions to extended its capability such as travel measurement, cycling, loadholding, etc., may be purchased either upfront or enabled in the field through an activation code. This a-la-carte platform allows for custom configuration as appropriate for the application and budget.

Force and travel data can be output to a PC for graphing and analysis using MESUR™gauge software. Or, fully control the stand by a PC through a custom-written program with ASCII communication.

line
Kit Contents line

Mark-10 ESM303 High Performance Motorized Test Stand
G1024 extension rod, 2”
G1028 small hook
G1038 medium hook
G1039 coupling, #10-32F/F
G1009 compression plate, 2” dia.
G1030 thread adapter, 5/16-18M to #10-32F
Thumb screw for force gauge / indicator (4 - four)
Thumb screw for limit switch (2 - two)
Allen wrench set
Control panel
Control panel mounting bracket and hardware

line
Features
line

Compatible with all Mark-10 force gauges, accessories and grips
Mounting holes for bench mounting
Loading table with 25 #10-32 UNF holes for fixture mounting
Precision Acme screw and nut
Optional digital travel display

line
Specifications
line

Load capacity	300 lbF (1.5 kN) @ up to 24 in/min (610 mm/min) 200 lbF (1 kN) @ >24 in/min (610 mm/min)
Maximum travel distance	18.0 in (457 mm)
Speed range	Standard: 0.5 - 13 in/min (13 - 330 mm/min) Optional: 0.02 - 45 in/min (0.5 - 1,100 mm/min)
Speed setting accuracy	±0.2%
Speed variation with load	±0% (stepper motor driven)
Travel accuracy	±0.002 in per 10 in (±0.05 mm per 250 mm)
Travel resolution	0.001 in / 0.02 mm
Limit switch repeatability	0.001 in (0.03 mm)
Power	Universal input 80-240 VAC, 50/60 Hz
Weight	56.5 lb (25.6 kg)
Included accessories	G1024 5” extension rod, G1028 small hook, G1038 medium hook, G1039 #10-32 coupler, G1009 2” dia. compression plate, gauge/indicator mounting screws, Allen wrench set, and Resource CD.
Warranty	3 years
