Mountz 020442 EMT160-F EMT 160 Adjustable Torque Screwdriver 1/4" F/Hex Drive, Range 20-160 ozf.in - Gedore 060140

See More Torque Screwdrivers

Mountz 020442 EMT160-F EMT 160 Adjustable Torque Screwdriver 1/4" F/Hex Drive, Range 20-160 ozf.in - Gedore 060140

See More Torque Screwdrivers
Price:
$562.62
  • Hassle Free 30-Day Returns
  • Availability: Usually ships within 3-4 weeksBest Seller - Low Stock - Order Soon
  • FREE Ground Shipping View Faster Delivery Options
warrenty

Product Description
Mountz Gedore EMT Adjustable Torque Screwdriver - Ergo Quickset Adjustable
Torque Limiting Screwdriver for Production
The bi-directional cam “slips free” once the set torque has been reached making over-tightening impossible.
Micrometer adjustment allows for accurate tool setting.

The Mountz Gedore Ergo Micro Torque (EMT) Screwdriver is designed to apply a set amount of torque. A bi-directional cam “slips free” once the set torque has been reached making over-tightening impossible


line
Features
line

  • The preferred and certified ranges of these tools is in accordance with the requirements if ISO 6789:2003 (+/- 6% of setting).
  • Adjustment ring disengages to prevent incidental torque adjustment.
  • Precision radial ball clutch and cam allows for automatic resetting.
  • The “positive” locking system prevents incidental torque adjustment.
  • Ergonomic rubber hand grip.
  • Micrometer adjustment allows for accurate tool setting.
  • Color coded adjustment ring allow for differentiation of models.
  • ESD compliant (IEC 61340-5-1: 1998)
  • Removable T-bar on larger models provides extra leverage.

Note - does not affect torque setting accuracy.


line
Force Ranges
line

ModelRangeGraduationDrive
EMT60-M10 - 60 ozf.in1 ozf.in1/4” M/Sq. Dr.
EMT60-F10 - 60 ozf.in1 ozf.in1/4” F/Hex Dr.
EMT160-M20 - 160 ozf.in1 ozf.in1/4” M/Sq. Dr.
EMT160-F20 - 160 ozf.in1 ozf.in1/4” F/Hex Dr.
EMT4-M0.5 - 4 lbf.in0.1 lbf.in1/4” M/Sq. Dr.
EMT4-F0.5 - 4 lbf.in0.1 lbf.in1/4” F/Hex Dr.
EMT12-M2 - 12 lbf.in0.1 lbf.in1/4” M/Sq. Dr.
EMT12-F2 - 12 lbf.in0.1 lbf.in1/4” F/Hex Dr.
EMT50-M*10 - 50 lbf.in1 lbf.in1/4” M/Sq. Dr.
EMT50-F*10 - 50 lbf.in1 lbf.in1/4” F/Hex Dr.
EMT80-M*30 - 80 lbf.in1 lbf.in1/4” M/Sq. Dr.
EMT80-F*30 - 80 lbf.in1 lbf.in1/4” F/Hex Dr.
EMT40-M5 - 40 cN.m1 cN.m1/4” M/Sq. Dr.
EMT40-F5 - 40 cN.m1 cN.m1/4” F/Hex Dr.
EMT120-M20 - 120 cN.m1 cN.m1/4” M/Sq. Dr.
EMT120-F20 - 120 cN.m1 cN.m1/4” F/Hex Dr.
EMT6-M*1 - 6 N.m0.1 N.m1/4” M/Sq. Dr.
EMT6-F*1 - 6 N.m0.1 N.m1/4” F/Hex Dr.
EMT9-M*4 - 9 N.m0.1 N.m1/4” M/Sq. Dr.
EMT9-F*4 - 9 N.m0.1 N.m1/4” F/Hex Dr.

* Supplied with Sliding T-Bar


line
Downloads
line

Mountz EMT Adjustable Torque Screwdriver - Instruction Manual
