Digital Adjustable Torque Wrench
3 Models with Capacities up to 250 lb-ft / 340 Nm
9 Programmable Target Torque Set-points
The DAW Series of Digital Adjustable Torque Wrenches are designed for simple and precise measurements in industrial, automotive, aerospace, and many other applications. The DAW displays Real-Time and Peak torque on a large LCD display in ft-lb, in-lb,r N-m or kg-cm (user-selectable).
The DAW features rugged adjustable steel jaws and the ability to program 9 target setpoints. 12 bright LEDs and an audible alarm alert the operator when the applied torque approaches and reaches the desired target.
Kit Contents
- DAW Digital Adjustable Torque Wrench
- Calibration Certificate
- 2x AA batteries
- Carrying Case
- Instruction Manual
Features
- 9 Programmable Target Torque Set-points
- Displays Torque in-lbs, ft-lbs, N-m, Kg-cm (User selectable)
- CW operation (CCW with display facing away from operator)
- Peak or Real-Time (track) mode (User Selectable)
- Buzzer and LED indicator for the pre-settable target torque
- 50 data point memory
- Auto shutdown after 5 minutes of non use
- Includes Calibration Certificate
- CE Certified
Specifications
| Accuracy | CW 3% of indicated From 20 - 100% of capacity |
| Memory | 50 Readings for recall on display, no output, 9 Presets |
| Unit Selection | ft-lb, in-lb, N-m, kg-cm |
| Battery | 2x AA |
| Battery Life | 110 Continuous Hours | 1 Year Standby |
| Operating Temperature | -10°C ~ 60°C |
| Storage Temperature | -20°C ~ 70°C |
| Humidity | Up to 90% non-condensing |
| Warranty | 1 Year |
Ranges
Other ranges available, inquire
