Mark-10 Thread Adapters for Digital Force Gauges

Connect force gauges and attachments with different Mark-10 thread adapter sizes. For use between force gauges, test stands, grips, and attachments. Use them with a force gauge and a test stand to create a complete testing system

Model	Capacity lbF [N]	Length in [mm]	Thread A
G1051	100 [500]	0.55 [14.0]	#4-40M
G1050	100 [500]	0.75 [19.1]	#10-32F
G1039	200 [1,000]	0.75 [19.1]	#10-32F
G1030	200 [1,000]	0.50[12.7]	#10-32F
G1067	200 [1,000]	0.75 [19.1]	#10-32F
G1048	200 [1,000]	0.75 [19.1]	#10-32F
G1057	200 [1,000]	0.75 [19.1]	#10-32F
G1054	200 [1,000]	0.75 [19.1]	#10-32F
G1060	200 [1,000]	0.75 [19.1]	#10-32M
G1063	200 [1,000]	1.30 [33.0]	#10-32M
G1047	200 [1,000]	0.75 [19.1]	#10-32M
G1069	500 [2,500]	1.25 [31.8]	5/16-18F
G1037	500 [2,500]	1.00 [25.4]	5/16-18F
G1059	500 [2,500]	1.13 [28.7]	5/16-18F
G1066	500 [2,500]	0.75 [19.1]	5/16-18F
G1049	500 [2,500]	1.25 [31.8]	5/16-18F
G1040	500 [2,500]	0.92 [23.4]	5/16-18M
G1091	1,000 [5,000]	1.30 [33.0]	1/2-20F
G1041	500 [2,500]	1.06 [26.9]	1/2-20M
G1044*	Adapter plate, 1/2-20F*
AC1082	100 [500]	0.75 [19.1]	#10-32M
AC1082-1	500 [2,500]	1.00 [25.4]	5/16-18M
AC1082-2	2,000 [9,000]	1.50 [38.1]	1/2-20M

line

Model	Capacity lbF [N]	Length in [mm]	Thread B
G1051	100 [500]	0.55 [14.0]	#10-32M
G1050	100 [500]	0.75 [19.1]	#4-40M
G1039	200 [1,000]	0.75 [19.1]	#10-32F
G1030	200 [1,000]	0.50[12.7]	5/16-18M
G1067	200 [1,000]	0.75 [19.1]	1/2-20M
G1048	200 [1,000]	0.75 [19.1]	M4M
G1057	200 [1,000]	0.75 [19.1]	M6F
G1054	200 [1,000]	0.75 [19.1]	M6M
G1060	200 [1,000]	0.75 [19.1]	#10-32M
G1063	200 [1,000]	1.30 [33.0]	5/16-18F
G1047	200 [1,000]	0.75 [19.1]	M4F
G1069	500 [2,500]	1.25 [31.8]	1/4-28M
G1037	500 [2,500]	1.00 [25.4]	5/16-18F
G1059	500 [2,500]	1.13 [28.7]	1/2-20F
G1066	500 [2,500]	0.75 [19.1]	1/2-20M
G1049	500 [2,500]	1.25 [31.8]	M6M
G1040	500 [2,500]	0.92 [23.4]	5/16-18M
G1091	1,000 [5,000]	1.30 [33.0]	1/2-20F
G1041	500 [2,500]	1.06 [26.9]	5/16-18M
G1044*	Adapter plate, 1/2-20F*
AC1082	100 [500]	0.75 [19.1]	#10-32M
AC1082-1	500 [2,500]	1.00 [25.4]	5/16-18M
AC1082-2	2,000 [9,000]	1.50 [38.1]	1/2-20M

*Compatible with any Mark-10 test stand with a threaded hole matrix base plate, such as TSF, ESM303, etc.

line
Downloads
line

Mark-10 Thread Adapters for Digital Force Gauges - Data Sheet

ADD TO CART THE ITEMS YOU WOULD LIKE TO PURCHASE

Models

Price

Mark-10 G1050 Thread Adapter #4-40M - #10-32F, 100 lbf / 500 N Capacity View Model Details

$20.00

Mark-10 G1051 Thread Adapter #4-40M - #10-32M, 100 lbf / 500 N Capacity View Model Details

$20.00

Mark-10 G1039 Coupler #10-32F to #10-32F, 200 lbf / 1000 N Capacity View Model Details

$15.00

Mark-10 G1030 Thread Adapter #10-32F - 5/16-18M, 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1057 Thread Adapter #10-32F to M6F, 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1060 Thread Adapter #10-32M to #10-32M, 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1063 Thread Adapter #10-32M to 5/16-18F, 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1047 Thread Adapter #10-32F - M4F, 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1048 Thread Adapter M4M - #10-32F, 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1054 Thread Adapter M6 Male to 10-32 Female , 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1040 Thread Adapter 5/16-18M - 5/16-18M, 500 lbf / 2500 N Capacity View Model Details

$20.00

Mark-10 G1037 Coupler #5/16-18F to #5/16-18F, 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1049 Thread Adapter M6M - 5/16-18F, 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1059 Thread Adapter 5/16-18F to 1/2-20F, 500 lbf / 2500 N Capacity View Model Details

$20.00

Mark-10 G1067 Thread Adapter 1/2-20M to #10-32F, 200 lbf / 1000 N Capacity View Model Details

$20.00

Mark-10 G1041 Thread Adapter 1/2-20M - 5/16-18M, 500 lbf / 2500 N Capacity View Model Details

$20.00

Mark-10 G1066 Thread Adapter 5/16-18F to 1/2-20M, 500 lbf / 2500 N Capacity View Model Details

$20.00

Mark-10 G1069 Thread Adapter 5/16-18F to 1/4-28M, 500 lbf / 2500 N Capacity View Model Details

$20.00

Recommended Accessories

PRICE

Mark-10 G1044 Adapter plate, 1/2-20F

$66.00
