    Humimeter RH5 Paper Moisture Meter
    Can also be used for normal relative air humidity measurement

    The Humimeter RH5 Paper Moisture Meter is specifically designed for measuring moisture content in paper by inserting the "sword probe" into a stack/pile of paper. The measured values can be manually entered into datalogger or can be set to automatically record at pre-set intervals.

    The temperature is measured as well and included in the hygromeasurement. Temperature range for measurement is -10 to +60 °C and can either be displayed in °C or °F. The RH5 hygrometer can measure the moisture content in paper or alternatively be used to measure relative air humidity measurements or dew point.

    An optional USB output module (RH5-USB) is available for transferring recorded data to a PC or printer for analysis/documentation. It is supplied with FREE software, a data link cable for connection to a PC and printer, and a USB adapter. There is also an option for a thermal printer with which you can print you measured values without a PC directly from the instrument.For additional protection, we recommend the optional protection sleeve (p/n RH5-SLEEVE) available to prevent the sensor or gauge being damaged during the "insertion" process. A sleeve removal tool is also recommended.


    line
    Kit Contents
    line

    • RH5 Moisture Meter
    • Wooden Case
    • Batteries
    • User Manual


    line
    Features
    line

    • Measurement accuracy of ±1.5% & resolution of 0.1%
    • Data can be manually entered into datalogger or can be set to automatically record at pre-set intervals
    • Optional USB output is used to transfer stored data to a PC. Includes software & transfer cable
    • Supplied with wooden case and batteries
    • Measures temperature using Pt 1000 probe & calculates Dew Point
    • Menu language in English, German, French, Italian, Spanish and Russian
    • Using unique "sword" sensor element to penetrate paper roll
    • 2-Year Warranty


    line
    Specifications
    line

    Measurnig Range0 to 100%
    Resolution0.1%
    Accuracy±1.5% (0 to 90%) at 25°C
    Temperature Range-10 to +60°C (14 to 140°F)
    Temperature Resolution0.1°C (0.1°F)
    Temperature Unitscan be set to °C and °F
    Temperature Accuracy±0.4°C (at 25°C) Pt 1000 DIN B
    Dew Point Temperature Range-55 to 60°C (-67 to 140°F)
    Dew Point Temperature Resolution0.1°C
    Date LoggerAutomatic data log for 10.000 logs with measuring point report (optional)
    Complete KitRH5 Moisture Meter, Wooden Case, Batteries, User Manual
    Optionally AvailablePC-interface, software and printer
    Warranty2 years
