Product Description

Limited Access Applications
9 Ranges, 3-30 g to 200-2000 g

Long, flat fingers and miniature V-grooved rollers are used in applications where there is limited access space or where the running filaments are close together.

Measuring Head Dimensions

  • Head Width (X): 38 mm
  • Head Length (Y): 47 mm


line
Features
line

  • 22 mm distance between outer rollers permits a narrow access "window" of only 1/2" x 1 - 1/2".
  • Rollers are rated for speeds up to 900 m/min. or, optionally, up to 2000 m/min (K).
  • Turned-up outer finger edges guide the running filament into the roller grooves, eliminating snags behind the rollers.

*Note: Can be calibrated for cN units, add sufix "-CN" to end of part number

DX2F Dial Faces

*Note: not all scales are shown


line
Specifications
line

Accuracy ± 1% of full scale or
± 1 graduation mark on scale
Diameter of Scale 41 mm
Maximum Speed 6000 m/min
Roller Material Hard-coated aluminum (standard)
Hardened steel (ST)
Chromed Steel (w)
Plastic (PL)
Housing Material Die-cast aluminum
Dimensions 225 x 90 x 44 mm
(8.6" x 3.5" x 1.7")


line
Thread Guides
line

Model Range Model Range
DX2F-3 3-30 grams DX2F-40 10-400 grams
DX2F-5 5-50 grams DX2F-80 100-800 grams
DX2F-12 10-120 grams DX2F-SP 50-1000 grams
DX2F-20-ALT 10-200 grams DX2F-EX 100-1000 grams
DX2F-20 20-200 grams DX2F-200 200-2000 grams
DX2F-30 20-300 grams
